Irrigation HDPE Pipes
HDPE pipes for pressurised agricultural water mains and field irrigation networks.
What is it?
Irrigation HDPE pipes are polyethylene pressure pipes that form the pressurised mains between water sources, pumps and field irrigation systems including drip and sprinkler zones.
In agriculture, HDPE forms the pressurised mains between the well, pump station and field irrigation network. Bukan Pipe lists pressurised irrigation among the primary applications for its polyethylene pipe production from 16 mm to 630 mm, pressure rating 2.5 to 25 bar.
Technical specifications
| Pipe type | Single-wall HDPE extrusion |
|---|---|
| Production range | 16 mm to 630 mm, pressure rating 2.5 to 25 bar (depending on grade and SDR) |
| Typical service | Pressurised irrigation feeder mains |
| Pressure class | PN per hydraulic design and pump duty |
| Jointing | Butt fusion for mains; electrofusion where specified |
| Manufacturer | Bukan Pipe — Bukan, West Azerbaijan, Iran. Manufacturing since 1997. |
Technical advantages
- Handles pump cycling and field pressure variation
- Flexible routing across farm terrain
- Faster repair and extension than rigid alternatives
- Corrosion resistance to irrigation water chemistry
Typical applications
- Pressurised irrigation feeder mains
- Water transfer from borehole to storage and field header
- Supply lines to drip, sprinkler and micro-irrigation zones
Catalogue dimensions — sample
Source: official Bukan Pipe catalogue
| Nominal size(mm) | S 4SDR 9 | S 5SDR 11 | S 6.3SDR 13.6 | S 8SDR 17 | S 10SDR 21 | S 12.5SDR 26 |
|---|---|---|---|---|---|---|
| PE32 · PE406 · 8 | PE32 · PE40— · 6 | PE32 · PE404 · — | PE32 · PE40— · 4 | PE32 · PE402.5 · — | PE32 · PE40— · 2.5 | |
| 16 | 1.8 – 2.1 | 1.5 – 1.8 | 1.2 – 1.5 | 1 – 1.3 | — | — |
| 20 | 2.3 – 2.7 | 1.9 – 2.3 | 1.5 – 1.8 | 1.2 – 1.5 | 1 – 1.3 | — |
| 25 | 2.8 – 3.2 | 2.3 – 2.7 | 1.9 – 2.3 | 1.5 – 1.8 | 1.2 – 1.5 | 1 – 1.3 |
| 32 | 3.6 – 4.1 | 2.9 – 3.3 | 2.4 – 2.8 | 1.9 – 2.2 | 1.6 – 1.9 | 1.3 – 1.6 |
For a project order, confirm the final specification with our sales team. Request a quote
Technical specifications
Contact sales or request a quote for diameter, SDR, PN and weight-per-metre tables matched to your project.
Standards and project compliance
For subsurface irrigation design, see the Technical Center article and consult project engineering.
Quality control
Pressure and dimensional testing in QC.
FAQ
- Can the same HDPE pipe serve irrigation and potable water?
- Material and production standard follow the project specification. Potable networks may require INSO 14427-2 production — confirm with sales for your application.
