HDPE Drainage Pipe
Polyethylene pipe for surface water and subsurface drainage.
What is it?
HDPE drainage pipes convey stormwater, surface runoff and subsurface drainage — distinct from sanitary sewer service.
Drainage addresses surface runoff, infiltration and complementary civil flows — not sanitary sewage. HDPE offers hydraulic capacity, flexibility and soil durability for these networks.
Technical specifications
| Pipe type | Single-wall HDPE extrusion |
|---|---|
| Production range | 16 mm to 630 mm, pressure rating 2.5 to 25 bar (depending on grade and SDR) |
| Service | Stormwater and surface drainage |
| Installation | Buried or exposed per civil design |
| Manufacturer | Bukan Pipe — Bukan, West Azerbaijan, Iran. Manufacturing since 1997. |
Technical advantages
- Smooth bore for hydraulic capacity
- Rapid installation on road and site projects
- UV exposure must follow project specification for above-ground runs
- Fewer fittings on flexible alignments
Typical applications
- Road and industrial yard drainage
- Agricultural and site stormwater routing
- Complementary networks alongside sewer lines
Drainage is not sewerage
The two get conflated in enquiries and the wrong product follows. Sanitary sewage is a continuous organic-loaded flow bound for treatment. Drainage is intermittent, driven by rainfall, and usually discharges to surface water. Pollution load, flow pattern and discharge point all differ, so the design diameter differs too.
Sizing a drainage line
Unlike a water main, which starts from design pressure, drainage starts from peak flow: design rainfall intensity times catchment area times runoff coefficient. That gives a flow rate, and the diameter follows from hydraulic capacity at the available gradient. Because the line is gravity-driven and carries little internal pressure, a heavy wall is not what matters — resistance to soil and traffic load on the buried pipe is.
Supply form in the catalogue
The catalogue marks its consumption column for water supply and sewerage and carries no separate drainage row. Drainage pipe is supplied from the same production range; the table below shows which diameters each SDR covers and whether it ships as a coil or a 12 m branch. Confirm availability of your diameter and SDR combination with sales before ordering.
Source: official Bukan Pipe catalogue
| SDR | Nominal pressure (atm) | Size range (mm) | Package | Length (m) |
|---|---|---|---|---|
| 41 | 3.2 | 315–630 | branch | 12 |
| 33 | 4 | 315–630 | branch | 12 |
| 26 | 5 | 50–630 | branch | 12 |
| 21 | 6 | 40–75 | coil | 100 |
| 21 | 6 | 90–630 | branch | 12 |
| 17 | 8 | 32–63 | coil | 200 |
| 17 | 8 | 75–125 | coil | 100 |
| 17 | 8 | 140–630 | branch | 12 |
| 13.6 | 10 | 25–63 | coil | 200 |
| 13.6 | 10 | 75–125 | coil | 100 |
| 13.6 | 10 | 140–630 | branch | 12 |
| 9, 7.4, 6 | 16, 20, 25 | 20–32 | coil | 200 |
| 9, 7.4, 6 | 16, 20, 25 | 40–75 | coil | 100 |
| 9, 7.4, 6 | 16, 20, 25 | 90–630 | branch | 12 |
For a project order, confirm the final specification with our sales team. Request a quote
Technical specifications
Contact sales or request a quote for diameter, SDR, PN and weight-per-metre tables matched to your project.
Standards and project compliance
Diameter and gradient follow hydraulic design and construction drawings.
Quality control
Production QC aligned with other PE pipe families.
FAQ
- What is the difference between drainage pipe and sewer pipe?
- Drainage carries stormwater and surface runoff — intermittent flow that usually discharges to surface water. Sanitary sewer carries continuous organic-loaded flow to treatment. The flow pattern and discharge point differ, so the design diameter differs.
- How is drainage pipe diameter selected?
- From peak runoff: design rainfall intensity, catchment area and runoff coefficient. The diameter then follows from hydraulic capacity at the available gradient. Use the pipeline design calculator for a first pass and have the result confirmed by the design engineer.
- What diameters of HDPE drainage pipe are available?
- The catalogue has no separate drainage row; drainage pipe comes from the same production range. The supply form table on this page shows the diameter band and packing for each SDR. Confirm your combination with sales before ordering.
- What SDR does drainage pipe need?
- A gravity drainage line carries little internal pressure, so a heavy wall is not required. What governs a buried pipe is soil and traffic load, and the quality of bedding and compaction around it. If your specification calls for a stiffness class, confirm before ordering.
